Mechanical Shutter The mechanical shutter completely blocks out light to eliminate light leakage for situations that require total darkness, such as during concerts. Lens memory Equipped with 10 customizable memory settings for image size, position, and focus, the projector detects and optimizes source material with various aspect ratios onto the projection area. Quick-Release Button for Lens Swaps The hot-swappable lens unlocks instantly with the quick-release button for lens changes.ģ60° Tilt Projection The projector can be tilted vertically at any angle, allowing projection onto ceilings, walls, floors, or angled signage.
GPROJECTOR HELP MANUAL
The lenses attach and detach with one-touch ease, manual adjustment for focus/zoom/lens shift. Interchangeable Lens (group2) Optimizing projector performance for all venues and applications, five types of optical lenses comprising short-throw to long-throw are available. The lenses attach and detach with one-touch ease, motorized adjustment for focus/zoom/lens shift. Interchangeable Lens (group1) Optimizing projector performance for all venues and applications, seven types of optical lenses comprising short-throw to long-throw are available.
GPROJECTOR HELP FULL
Interchangeable Colour wheel An additional 6-segment colour wheel is included as a standard accessory, which allow user to full fill different occasions and requirement by changing the two colour wheels. SmartEco Offering lower TCO and optimized projection through dynamic power saving, uncompromised brightness, exquisite picture quality and optimized lamp life. It is measured as an offset from the projected image’s vertical or horizontal centre.īrilliant colour Brilliant Colour offers up to 6-color processing to boost secondary colours and deliver reliable and precise colour for long lasting period. The lens shift is expressed as a percentage of the projected image height or width. It allows the projector to be positioned off the centre of the screen. Lens shift The lens shift control provides flexibility for installing your projector. The bigger zoom ratio can give you better installation flexibility with larger range of throw distances. Zoom ratio Zoom ratio is the ratio of the shortest and longest ranges of a zoom lens.
A shorter throw ratio corresponds to a shorter throwing distance from projector to the screen. Throw ratio Throw ratio refers to the ratio of “the distance to the screen” to “the screen width”. ANSI lumens are the result of an average of 9 measurements. This surface is sub-divided into 9 zones which is measured in lux brightness at the centre. Invented by Texas Instruments, DLP technology is based on an optical semiconductor called the DMD (Digital MicroMirror Device) chip.ĪNSI lumens (American National Standard Institute) ANSI measure considers a white picture projected on the entire surface of a screen of 102cm diagonal.
DLP technology uses an all-digital chip to project and display images.
GPROJECTOR HELP HOW TO
Refer to user manual for instructions on how to reset the lamp life timer.DLP (Digital Light Processing) DLP projectors provide excellent brightness / compactness. Note: The lamp module must sit securely in place and the lamp connector must be connected properly before tightening the screws.ħ. While installing, align the lamp module with the connector and ensure it is level to avoid damage.
GPROJECTOR HELP INSTALL
Reverse steps 1 to 5 to install the new lamp module. Pull firmly on the module handle to remove the lamp module.Ħ. Remove the screws from the lamp module with a Phillips Screwdriverĥ. Remove the single screw on the lamp compartment cover with a Phillips screwdriver.ģ. Please refer to user manual for accurate instructions on how to replace the projector lamp on your model.ġ. Failure to do so could result in a severe burn. The illustrations may differ from your product, and are meant as general examples. For more information, contact the Electronic Industries Alliance at For lamp specific disposal information check Warning: Be sure to turn off and unplug the projector at least 30 minutes before replacing the lamp. Recycle or dispose in accordance with local, state, or federal Laws. This product may contain other electronic waste that can be hazardous if not disposed of properly. Lamp(s) inside this product contain mercury. See below notice for recycling instructionsĬ. Disposal of this product must be carried out in accordance with the regulations of your local authority Do not dispose this product with general household waste. The projection lamp used in projector lamps can contain a small amount of mercury.ī. It should only be replaced with a certified replacement part, which you can order from your local dealer.Ī. The projection lamp should be replaced when it burns out.
